Burndy YC-C Style Crimp Connectors by Farwest Corrosion
SKU#: CrimpConnector
"C" Shape Compression Connector for Tap or Parallel Copper Cable
Description
Type YC-C copper crimpit connector is a range-taking "C" shape compression connector for making tap or parallel copper connection from #12 solid to 4/0 stranded conductors.
Ordering Information
Burndy No
Farwest No.
Wire range run
Wire range tap
YC10C10
12-10100
12 Sol - 10 Str
12 Sol - 10 Str
YC8C8
12-10102
8 Sol - 8 Str
10 Sol - 8 Str
YC4C8
12-10104
6 Sol - 4 Str
8 Sol - 8 Str
YC4C6
12-10106
6 Sol - 4 Str
6 Sol - 6 Str
YC4C4
12-10108
6 Sol - 4 Str
4 Sol - 4 Str
YC2C4
12-10110
2 Sol - 2 Str
8 Sol - 4 Str
YC2C2
12-10112
2 Sol - 2 Str
2 Sol - 2 Str
YC26C2
12-10114
1/0 Str - 2/0 Str
8 Sol - 2 Str
YC26C26
12-10116
1/0 Str - 2/0 Str
1/0 Str - 2/0 Str
YC28C2
12-10118
3/0 Str - 4/0 Str
6 Sol - 2 Str
YC28C26
12-10120
3/0 Str - 4/0 Str
1/0 Str -2/0 Str
YC28C28
12-10122
3/0 Str - 4/0 Str
3/0 Str - 4/0 Str
Specifications
Dimensional
Length (Fraction)
3/8
General
Product Description
Range-taking compression tap connector made of pure copper. For Copper to Copper applications. Designed to be gripped in the jaws or dies of installation tool, then slipped directly over line for easy installation. Also used for deadending.
Type YC-C copper crimpit connector is a range-taking "C" shape compression connector for making tap or parallel copper connection from #12 solid to 4/0 stranded conductors.
Ordering Information
Burndy No
Farwest No.
Wire range run
Wire range tap
YC10C10
12-10100
12 Sol - 10 Str
12 Sol - 10 Str
YC8C8
12-10102
8 Sol - 8 Str
10 Sol - 8 Str
YC4C8
12-10104
6 Sol - 4 Str
8 Sol - 8 Str
YC4C6
12-10106
6 Sol - 4 Str
6 Sol - 6 Str
YC4C4
12-10108
6 Sol - 4 Str
4 Sol - 4 Str
YC2C4
12-10110
2 Sol - 2 Str
8 Sol - 4 Str
YC2C2
12-10112
2 Sol - 2 Str
2 Sol - 2 Str
YC26C2
12-10114
1/0 Str - 2/0 Str
8 Sol - 2 Str
YC26C26
12-10116
1/0 Str - 2/0 Str
1/0 Str - 2/0 Str
YC28C2
12-10118
3/0 Str - 4/0 Str
6 Sol - 2 Str
YC28C26
12-10120
3/0 Str - 4/0 Str
1/0 Str -2/0 Str
YC28C28
12-10122
3/0 Str - 4/0 Str
3/0 Str - 4/0 Str
Specifications
Dimensional
Length (Fraction)
3/8
General
Product Description
Range-taking compression tap connector made of pure copper. For Copper to Copper applications. Designed to be gripped in the jaws or dies of installation tool, then slipped directly over line for easy installation. Also used for deadending.
