Poistest LPD

Low voltage Pinhole Detector for Metal and Concrete Substrates
Detects holidays, pinholes and other discontinuities in coatings on metal and concrete substrates.
- GroundSense visibly reassures the user that the instrument is properly grounded
- 4 voltage output options conform to a variety of standards
- Weatherproof, dustproof and shockproof - meets or exceeds IP65
- Rugged, environmentally sealed enclosure
- Two year warranty
- Certificate of Calibration showing traceability to NIST included (Long Form)
Conforms to ISO 14654, ISO 8289-A, ASTM G62, G6, D5162, BS7793-2, NACE TM0384, SP0188, AS3894.2, JIS K 6766
Simple

Easy-to-use interface with bright, multi-function LEDs

Ready to measure -- both kits come with everything needed for testing

Audibly and visibly alerts when flaws are detected

Light, ergonomic design
Durable

Rugged, environmentally sealed enclosure

Weatherproof, dustproof and shockproof -- meets or exceeds IP65

Two year warranty
Accurate

Automatic self-test verifies voltage calibration

Regulated voltage outputs will not drop under load

Long Form Certificate of Calibration included

GroundSense™ visibly reassures the user that the instrument is properly grounded

Conforms to international standards including ISO, ASTM and NACE
Versatile

A wide range of adaptable sponge hardware for a variety of test configurations

Common threads and connectors allow for maximum flexibility

Headphone jack with included earbud for noisy environments

Uses 3 AAA alkaline or rechargeable batteries

4 voltage output options conform to a variety of standards
Specifications

Voltage Setting

9V ± 5%

67.5V ± 5%

67.5V ± 5%

90V ± 5%

Sensitivity

90k ± 3%

80k ± 3%

90k ± 3%

400k ± 3%

0 – 500 μm (0 – 20 mils)

Thickness Range

Temperature Range

Battery Life

IP Rating

Size

-10 – 50° C (14 – 122° F)

Weight

> 150 hrs (depending on battery type)

meets or exceeds IP65

27 x 6 x 5.5 cm (10.6" x 2.3" x 2.1") without wand

180 g (6.4 oz.) without batteries
