Positector SHD

Shore Hardness Durometers for the indentation hardness of non-metallic materials
Handheld electronic instrument measures the indentation hardness of non-metallic materials. Two durometer models are available for different hardness ranges – Shore A and Shore D.
- User-adjustable measurement time with onscreen countdown to conform to national and international standards
- Auto Ignore mode disregards hardness readings below 20 and above 90 per international standards
- Solvent, acid, oil, water, and dust resistant – weatherproof
- PosiTector interchangeable platform – attach any PosiTector probe to a single gage body
- USB, WiFi, and Bluetooth connectivity to PosiSoft PC, Mac, and Smartphone software
- Certificate of Calibration showing traceability to NIST included (Long Form)
Conforms to ASTM D2240, ISO 868/7267/7619 and DIN 53505
Simple

Easy-to-read digital display

User-adjustable measurement time with onscreen countdown to conform to national and international standards

Enhanced one-handed menu navigation

RESET feature instantly restores factory settings
Durable

Solvent, acid, oil, water and dust resistant - weatherproof

Shock-absorbing, protective rubber holster with belt clip

Hardened steel indentor

Two year warranty on gage body AND probe
Accurate

Certificate of Calibration showing traceability to NIST included (Long Form)

Auto Ignore mode disregards hardness readings below 20 and above 90 per international standards

Hi-RES mode increases displayed resolution to 0.1

Includes test block to verify operation

Conforms to ASTM D2240, ISO 868/7267/7619 and DIN 53505
Versatile

High contrast backlit display for bright or dark environments

Selectable display languages

Flip display enables right-side-up viewing

Uses alkaline or rechargeable batteries (built-in charger)
Powerful

Continually displays/updates average, standard deviation, min/max hardness and number of readings while measuring

HiLo alarm audibly and visibly alerts when measurements exceed user-specified limits

Sealed USB Port for fast, simple connection to a PC and to supply continuous power. USB cable included

Software Updates via web keep your gage current

Screen Capture – record and save image into USB flash memory for record keeping and review

Software Solutions for viewing, analyzing & reporting data

Every stored measurement is date and time stamped
Specifications

Measurement Range

0 – 100

Accuracy

± 1

Resolution

0.1

Body Size

137 x 61 x 28 mm (5.4" x 2.4" x 1.1")

Weight

185 g (6.5 oz.) without batteries

All gages come complete with test block, protective rubber holster with belt clip, wrist strap, 3 AAA alkaline batteries, instructions, nylon carrying case with shoulder strap, Long Form Certificate of Calibration traceable to NIST, protective lens shield, USB cable, PosiSoft Software, two (2) year warranty.
PosiTector SHD Full Instruction Manual

PDF Document

PosiTector SHD Quick Guide

PDF Document

PosiTector SHD Literature

PDF Document
