Trace-Safe Water Blocking Connetors

TRACE-SAFE Water Blocking Connector is compact, durable and easy to use in the field.

Description

TRACE-SAFE Water Blocking Connector is compact, durable and easy to use in the field.

TRACE-SAFE WATER BLOCKING CONNECTORS

For use with TRACE-SAFE Water Blocking Tracer Wire

TRACE-SAFE Water Blocking Connector is compact, durable and easy to use in the field. Application Includes	P / N
TRACE-SAFE main line end to end butt splice	T-S 19IL
TRACE-SAFE main line lateral connection - TRACE-SAFE® main to lateral	T-S 19
TRACE-SAFE main line butt splice to an existing 10, 12, 14 AWG main line tracer wire	T-S 12-19IL
TRACE-SAFE lateral to existing 10, 12, 14 AWG main line tracer wire	T-S 12-19

Trace-Safe End to End Butt Splice		Trace-Safe Main to Lateral


Trace-Safe to 12 AWG Butt Splice		12 AWG Main to Trace-Safe lateral

TRACE-SAFE connectors were evaluated to:

UL 467-2007
Grounding and bonding equipment
Chase 9.5 - short time current test

UL 486A - 486B - 2003
Standard for wire connectors
Chase 9.3.4 - pullout test

ASTM B117-09 - salt spray fog test

Product specification and dimensions:

Material	High strength glass filled polycarbonate
Connector Dimension	1 7/16" L x 23/32" W x 23/32" H
Water Blocking	Filled with sealrite water blocking non-hardening gel
Conductor Range	10 AWG - 19 AWG solid copper

Instructions

Click to enlarge
