Gal-Vo-Plast® is the new standard coating to replace galvanizing.
Description
Gal-Vo-Plast® wall sleeves prevent corrosion for better durability and longer life. APS offers stainless steel, carbon steel, and Gal-vo-plast® wall sleeves in 12” standard lengths with a 2” water stop. Diameters range from 2” to 120” and custom lengths are available.
Two wall sleeves with two different types of protective coatings were submitted for testing at an independent lab. This test consisted of a 500-hour exposure test (equal to two years) in a B 117 salt fog chamber. This test has been used to a considerable extent for the purpose of comparing different materials and finishes.
One sample had hot dipped galvanized coating and the other had Gal-vo-plast coating. The coatings were of uniform thickness and showed good adhesion.After testing, the submitted wall sleeves were removed from the salt fog chamber for visual examination.
The visual examination revealed no indications of oxidation on any of the exposed surfaces of theGal-vo-plast coating. The visual examination revealed considerable oxidation of the galvanized coating on all exposed surfaces.
Comparison
Gal-vo-plast Wall Sleeve after 500 hours of exposure
Galvanized Wall Sleeve after 500 hours of exposure
Gal-vo-plast Wall Sleeves
Galvanized Wall Sleeves
More durable
Faster availability, especially for custom wall sleeves
Longer installation life
All coating performed in-house
Considerably more economical
Does not resist corrosion as long
Custom wall sleeves usually require an additional two weeks to galvanize
More expensive
Must be sent out of factory to be galvanized
Specifications
Quality Assurance• Corrosion Resistant
Unlimited Sizes• Easy Installation
Customized To Order
Fast Turn-around
APS traditional wall sleeves are available in stainless steel and carbon steel with our new Infinity wall sleeve manufactured in HDPE. The standard length is 12”; longer and shorter lengths are available. Steel wall sleeves are available in sizes from 2” to 120” diameter.
Steel Wall Sleeve
Nominal Size (in)
Sleeve I.D. (in)
2
2.067
2-1/2
2.469
3
3.068
3-1/2
3.548
4
4.026
6
6.065
8
7.981
10
10.020
12
12.000
14
13.250
16
15.250
18
17.250
20
19.250
22
21.250
24
23.250
26
25.250
28
27.250
30
29.250
32
31.250
34
33.250
36
35.250
40
39.250
42
41.250
Larger sizes available up to 120"
Infinity Wall Sleeves
Model
I.D. (in)
lbs.
IS-2
1.98
0.70
IS-3
2.94
1.30
IS-3.5
3.38
1.50
IS-4
4.03
2.00
IS-5
5.14
2.80
IS-6
6.14
3.60
IS-8
8.21
4.80
IS-10
10.19
6.40
IS-12
12.26
7.20
IS-14
14.14
11.20
IS-16
16.18
12.00
IS-18
17.45
15.50
IS-20
19.12
17.50
IS-22
20.32
21.00
IS-24
22.76
22.00
IS-25
24.81
23.00
