CT 25-3 - Portable Current Source

SKU#: CT 25-3
Model CT 25-3 is used for testing small sections of galvanically protected gas distribution systems, underground structures, and pipelines. The CT 25-3 was specifically designed to carry out current demand surveys on pipeline segments of gas distribution systems or small underground structures, protected with directly connected galvanic anodes.

Characteristics:
- Recharging is unnecessary (the unit uses 9V batteries).
- Rechargeable 9 V batteries can be installed if desired.
- Integrated voltage and current meters, increasing ease of use. (not for calibrated readings)
- Easy connection to a calibrated, external volt meter (for output voltage, current and structure potential if connected to a reference electrode).
- Shunt reading 1 mV=1 mA (no conversion necessary).
- Adjustable output voltage (from minimum = 1.5 VDC up to maximum of 25.0 VDC, approx.).
- Off button to check polarization response.
- Reliable and easy to operate.
- Durable plastic case protects instrument from impact.
- Wide range of voltages is especially useful for temporary anode beds where high resistance is common.
- 3 Amp maximum current.

Characteristics:

Recharging is unnecessary (the unit uses 9V batteries).
Rechargeable 9 V batteries can be installed if desired.
Integrated voltage and current meters, increasing ease of use. (not for calibrated readings)
Easy connection to a calibrated, external volt meter (for output voltage, current and structure potential if connected to a reference electrode).
Shunt reading 1 mV=1 mA (no conversion necessary).
Adjustable output voltage (from minimum = 1.5 VDC up to maximum of 25.0 VDC, approx.).
Off button to check polarization response.
Reliable and easy to operate.
Durable plastic case protects instrument from impact.
Wide range of voltages is especially useful for temporary anode beds where high resistance is common.
3 Amp maximum current.
