Economical Mechanical Protection for Pipeline Corrosion Coatings
Description
Trenton Utility Tape Outerwrap requires no specific surface preparation and can be applied in a wide variety of environmental conditions. It is simply spiralwrapped, with an overlap, over the existing corrosion coating. No special tools required.
Features
Easy to apply
No tools required
Durable mechanical protection
Good impact resistance
Economical
Compatible with multiple coatings
Application
Pipeline coating applications that might be subjected to severe soil stress or mechanical impingement can benefit from the protection of an additional outerwrap. Trenton Utility Tape Outerwrap is a cost-effective solution for applications where there is limited potential for impact on cathodic protection systems.
Typical Applications
Additional mechanical protection for:
Wax-Tape® Wraps
Epoxy coatings
FBE
PE
Other pipeline coatings
Application Procedures
Surface should be clean and dry at the time of application.
Apply adhesive/sticky face of Trenton Utility Tape Outerwrap to the surface to be covered and commence wrapping, using tension to ensure conformability and intimate adhesion.
Overlaps should be a minimum of 10% or greater as specified. End laps should be a minimum of 55% of tape width.
Specifications
PVC film with synthetic rubber adhesive
Properties
English
Metric
Thickness
10 mil
0.25 mm
Adhesion to steel
20 oz/in
232 g/cm
Tensile strenght
25 lbs/in
225 N/50 mm
Elongation
200%
200%
Dielectric strenght
10 kV
10 kV
Maximum operational temperature
176°F
80°C
Packaging
Trenton Utility Tape Outerwrap is available in:
10 mil thickness
4" x 100' (10cm x 30.4m) rolls (12 rolls/case)
6" x 100' (15cm x 30.4m) rolls (8 rolls/case)
20 mil thickness
4" x 100' (10cm x 30.4m) rolls (12 rolls/case)
6" x 100' (15cm x 30.4m) rolls (8 rolls/case)
Quantity Estimates
Tap Width
Rolls/ Case
Coverage w/ 1" Overlap
Coverage w/ 50% Overlap
4"
12 rolls/case
360 sq. ft.
200 sq. ft.
6"
8 rolls/case
360 sq. ft.
200 sq. ft.
