Non-Pressure Pipe, Joint & Crack Repair Kits By Neptune Research, Inc.

Repairs broken or cracked pipes and joints. Ready to use, heat resistant, no mixing, no mess, sets rock hard in minutes

Product Information

Syntho-Glass® repairs broken or cracked pipes damaged through everyday wear or when an unexpected emergency occurs. It is patented and easy to use for quick action.

Typical Applications
Non-pressure repair and protection for:

Cracked piping
Leaking joints
Corroded pipes
Emergency repair
Potable waterlines
Irregular pipe fittings

Benefits

Ready to use
Heat resistant
Effective time saving
No mixing & no mess
Sets rock hard
NSF61 approved

Repair Kit Contents

Syntho-Glass®
Butyl Patch
Syntho-Steel™ Putty
Gloves
Instructions

Properties

Physical Properties
Resistance Temperature to Heat Resistance Temperature to Cold Gasoline & Oil Alcohol Water Low Concentration Mineral Acid High Concentration Mineral Acid High Concentration Alkali Low Concentration Alkali	300°F -50°F OK OK OK OK OK OK OK
Mechanical Properties
Tensile Strength Lap Shear Strenght Flexural Strength Dielectric Strength	38,000 psi 900 psi 18,000 psi 16,000 volts

Preparation & Application
(Maximum pressure use of UP kit is 60 psi)
Installation Guide in pdf Format

1a.

Joint / Potable water systems: Knead putty until uniform in color. Roll into a rope or ball. Place firmly into joint or crack. Feather edges with wet finger.

1b.	Crack: Remove adhesive backing from Butyl Patch and apply directly over break; press firmly onto pipe.

2.	Remove Syntho-Glass® from foil pouch using enclosed gloves. Soak in temperate water for 20 seconds.

3.	Tightly wrap Syntho-Glass using entire roll. Wrap approximately 2” above and below the repair and directly over the rubber tape.

4.	Squeeze and mold Syntho-Glass in the direction of wrap, removing excess water and spreading resin until tacky to touch (approximately 3-5 min.). Allow 30 minutes at 75°F before re-applying water pressure.

Ordering Information

Pipe Diameter Roll Size Kit #

1/2" - 1"
1-1/4" - 2"
2-1/2" - 4"
4-1/2" - 6" 2" x 5"
3" x 9'
4" x 15'
4" x 30' NP520
NP930
NP415
NP430

Product Information

Syntho-Glass® repairs broken or cracked pipes damaged through everyday wear or when an unexpected emergency occurs. It is patented and easy to use for quick action.

Typical Applications
Non-pressure repair and protection for:

Cracked piping
Leaking joints
Corroded pipes
Emergency repair
Potable waterlines
Irregular pipe fittings

Benefits

Ready to use
Heat resistant
Effective time saving
No mixing & no mess
Sets rock hard
NSF61 approved

Repair Kit Contents

Syntho-Glass®
Butyl Patch
Syntho-Steel™ Putty
Gloves
Instructions

Properties

Physical Properties
Resistance Temperature to Heat Resistance Temperature to Cold Gasoline & Oil Alcohol Water Low Concentration Mineral Acid High Concentration Mineral Acid High Concentration Alkali Low Concentration Alkali	300°F -50°F OK OK OK OK OK OK OK
Mechanical Properties
Tensile Strength Lap Shear Strenght Flexural Strength Dielectric Strength	38,000 psi 900 psi 18,000 psi 16,000 volts

Preparation & Application
(Maximum pressure use of UP kit is 60 psi)
Installation Guide in pdf Format

1a.

Joint / Potable water systems: Knead putty until uniform in color. Roll into a rope or ball. Place firmly into joint or crack. Feather edges with wet finger.

1b.	Crack: Remove adhesive backing from Butyl Patch and apply directly over break; press firmly onto pipe.

2.	Remove Syntho-Glass® from foil pouch using enclosed gloves. Soak in temperate water for 20 seconds.

3.	Tightly wrap Syntho-Glass using entire roll. Wrap approximately 2” above and below the repair and directly over the rubber tape.

4.	Squeeze and mold Syntho-Glass in the direction of wrap, removing excess water and spreading resin until tacky to touch (approximately 3-5 min.). Allow 30 minutes at 75°F before re-applying water pressure.

Ordering Information

Pipe Diameter	Roll Size	Kit #
1/2" - 1" 1-1/4" - 2" 2-1/2" - 4" 4-1/2" - 6"	2" x 5" 3" x 9' 4" x 15' 4" x 30'	NP520 NP930 NP415 NP430
